>Install between the engine and the oil filter Safe and secure mounting possible with no special work required
>Sizes compatible with major oil temperature and pressure gauges
Two types: PT1/8, M12xP1.25 (mm)
*Differ according to type
>Light, high quality, high precision aluminum cut attachments
>Supplied with genuine standard O-ring

>A special set of a micro oil sensor attachment and a thin filter. For heavy users who pursue light weight, high performance rotary powered vehicles and compact cars.
>PT1/8 sensor pitch suitable for mounting on electronic meters
>Less load to engine with reduced size
>Supplied with genuine standard O-ring
>Total thickness: 80 (mm) Low interference with road surface and gadgets
Weight DOWN 15 (%)
Volume DOWN 25 (%)

>Backup net (wire mesh) that has the same specification as racing cars prevents deformation and damage of filter paper and secure filter performance
>Highly heat resistant nitrile O-ring maintains sealing performance.
>The highly efficient filter paper exhibits high impurity capture capacity. It removes ultra fine wear debris, dust, and carbon and suppresses adverse effects on the engine to a minimum.

>Thin with a thickness of only 50mm Most suitable when used together with oil sensor attachment
>No back up, low cost

>Requires a part of the upper hose of radiator to be cut and inserted
>PT1/8 sensor pitch compatible with major water temperature gauges
>Provided in 8 sizes for vehicles from compact cars to sports cars
>Light, high quality, high precision aluminum cut attachment
>Colored anodized finishing dresses up your engine room
>Supplied with highly anti-corrosive stainless bands

>Elbow type water temperature sensor fitting
>PT1/8 sensor hole suitable for mounting on electronic meters
>Size setting for various sports cars: 30-38 (ø)
>Highly anti-corrosive aluminum body and stainless band

Compatible Vehicles (Reference):LEVIN TRUENO (AE111), ACCORD/TORNEO (CF4/CL1), ALTEZZA (SXE10), MR2 (SW20), MARK II series (JZX100), LANCER EVO. (CN/CP/CT9A), SILVIA (S13/14/15), IMPREZA (GDB), LEGACY (BE/BH/BL/BP)

>For oil temperature / oil pressure / fuel pressure gauges and for step down
>Vehicle specific special adaptors also available

Oil pressure exclusive to MAZDA 13B
MAZDA P1.75 oil temperature
Oil pressure exclusive to MAZDA L3-VE/L3-DE/LF-DE
Oil temperature/pressure exclusive to MITSUBISHI LANCER EVO., etc.

>Adheres well to metal surfaces
>Most suitable for linking sports meters Good for linking meters, such as turbometers and intake manifold meters
>Available in 2 types: CR or Silicon
>Available in a wide range of sizes, lengths, and colors

Silicon: High heat resistance, Beautiful colors
CR (chloroprene): High fatigue resistance

HOSE JOINER
>Straight & 3-way T type Joiners
>Heat and oil resistant

SUPER JOINER
>Brass Material
>Heat and oil resistant

>Damage-proof structure lowers the risk of damaging the hose
>Secure fastening prevents leakage

>Heat resistance: 538 (ºC)
>Tensile strength: 6430 (kg/cm²⁾
>2 sizes: 250 (mm ) / 3 (m)

>Sealing caps necessary during linking work
>4 / 6 / 8 / 12 / 15 / 20 / 30 / 34 (ø)
>Available in various sizes
